Closer Than You Think: Adding Nearest Neighbor Search to Ceph

We have been paying close attention to vector search since early 2024. The proliferation of RAG pipelines, semantic code search, and embedding-based recommendation systems made it clear that vector storage was going to become a first-class infrastructure concern, and that the object store was a natural candidate to take it on. We spent the better part of last year researching the landscape: evaluating ANN index structures and libraries, thinking through how vector operations would map onto RGW's request pipeline, and wrestling with the API design question — invent something from scratch, or wait for a standard to emerge?

Then AWS announced S3 Vectors, and the picture snapped into focus. A well-considered API, anchored to the S3 model Ceph already implements, with enough ecosystem weight behind it to drive real client adoption. We got to work.

The API ¶

S3 Vectors introduces a small set of new resource types on top of the familiar S3 model.

A Vector Bucket is a new bucket type that accepts only s3vectors:* operations — GetObject, PutObject, ListObjectsV2, and the rest of the standard S3 API are not permitted. Vector buckets support SSE-S3 and SSE-KMS, and are controlled through the same IAM intersection of identity-based and resource-based policies that Ceph already implements for conventional buckets.

Inside a vector bucket, an Index is an ANN index bound at creation time to a distance metric (cosine or euclidean) and a vector dimension count. Indexes are LanceDB tables under the covers — more on that below.

Vectors are dense float32 arrays stored alongside string metadata tags, with up to 10 key-value pairs and 40 KB of metadata per vector. QueryVectors performs a top-K ANN search against an index, with optional metadata predicate filtering evaluated in tandem with the search — candidates are checked against the filter as they are retrieved, so only matching vectors are counted toward the top-K result set. Queries with filters may return fewer than K results when very few vectors satisfy the predicate.

The full set of policy actions:

Internally, a vector bucket maps to a LanceDB dataset directory persisted through the RGW Storage Abstraction Layer, so the data lands in RADOS with whatever replication or erasure coding the cluster is configured for. The on-disk structure looks like this:

s3://my-bucket/           ← Vector Bucket
├── embeddings/           ← Index 'embeddings'
│   ├── data/             ← Lance column data files
│   ├── indices/          ← IVF-PQ index files
│   ├── _latest.manifest  ← Points to current version
│   └── schema.arrow      ← Index schema
└── thumbnails/           ← Index 'thumbnails'
    └── ...

Why This Belongs in Ceph ¶

The case for building vector search into the object store rather than pointing users at a dedicated vector database is simple: cost, simplicity, and co-location.

Cost first. A moderately sized RAG corpus can easily contain tens of millions of vectors. At 1,536 dimensions (OpenAI's text-embedding-3-small output), each vector is 6 KB of raw float32 data, putting 100M vectors at roughly 600 GB before indexing overhead. Running that in the memory-oriented tier of a dedicated vector database is expensive. Running it on Ceph's erasure-coded storage is not. Our target space amplification is ≤1:3 — raw vector data to total on-disk footprint including IVF-PQ index structures.

Simplicity: if you already run Ceph, enabling vector search requires no new daemons, no new hardware, and no new operational surface area. The capability lives inside the RGW request pipeline.

Co-location: organizations using Ceph as a document store or model artifact repository often want their embeddings in the same cluster as the source objects. Keeping them together eliminates a class of data movement and consistency problems that arise when the two systems diverge.

The Library: LanceDB via C Binding ¶

We evaluated three candidate ANN libraries.

FAISS is optimized for in-memory operation and GPU acceleration. Neither aligns with how Ceph gateway nodes are typically configured. Ruled out early.

DiskANN is technically well-suited — disk-native, SSD-optimized, supports L2 and cosine distance, MIT licensed, written in C++. The problem is that DiskANN provides only the algorithm. There is no built-in storage format, I/O layer, or query engine, which means substantial additional integration work to reach the same feature set as a embedded retrieval library for multimodal AI.

LanceDB is a full-stack library built on the Lance columnar format, designed from the ground up for fast random-access disk I/O. It uses IVF-PQ indexes, supports both distance metrics, includes hybrid ANN + scalar predicate search, and provides a clean API whose dataset/table/index model maps directly onto S3 Vectors' bucket/index/vector abstractions. Apache 2.0 licensed.

LanceDB is written in Rust. Ceph is C++. Bridging them required a C binding layer that did not previously exist. As part of this project we spearheaded the development of lancedb/lancedb-c, a C API for LanceDB that is being contributed back to the LanceDB community. The bindings expose the functions RGW needs — lancedb_table_create, lancedb_table_merge_insert, lancedb_table_query, lancedb_table_index_stats, and others — as a stable C API that Ceph links against via FFI. The binding repository also includes a working S3 Vectors simulator useful for local development without a full Ceph cluster, and a test dataset of 693 embeddings of Ceph source code at 1,024 dimensions, with function name, class name, and line number metadata.

LanceDB accelerates K-means clustering during index generation using AVX2 SIMD, confirmed for Euclidean (L2) distance. Cosine acceleration is worth benchmarking on target hardware. Index generation could also be GPU-accelerated via PyTorch (accelerator='cuda') in create_index, though Ceph gateway nodes do not typically have accelerators. If we want to go this route, we may need to look into using cuVS directly, since this appears to only apply to the Python lancedb libraries.

Writes: merge_insert and Background Optimization ¶

PutVectors accepts batches of up to 500 vectors or 20 MB, whichever is smaller, with a rate limitted number of calls per index per second. In AWS the limit is 5, but this is something we will expose as a configuration knob.

Under the hood we map PutVectors to LanceDB's merge_insert — an atomic upsert that checks for the existence of each vector by key and inserts or updates in a single operation. The alternative, separate read-then-write logic, introduces race conditions under concurrent writes.

After a merge_insert, new vectors are immediately searchable through a combined scan. In parallel, a background optimize() call can rebuild the IVF-PQ index without blocking concurrent writes or queries. We use LanceDB's built-in index_stats() API to track the ratio of indexed to unindexed rows and trigger a rebuild when the fraction of unindexed vectors exceeds a configurable threshold. This replaced an earlier approach that maintained external JSON counters with file locking. Letting LanceDB's own manifest stats do that work is simpler and more accurate.

Queries: IVF-PQ and the nprobes Tradeoff ¶

IVF-PQ partitions the vector space into cells (IVF) and compresses vectors using product quantization (PQ). At query time, nprobes controls how many IVF cells are examined. Higher values improve recall; lower values reduce latency. Our target query latency range is 100–800 ms, and nprobes is the primary tuning lever. The QueryVectors operation returns up to 30 nearest neighbors per call.

Metadata Filtering ¶

S3 Vectors supports per-vector metadata tags — up to 10 key-value pairs — with a distinction between filterable and non-filterable metadata. Deciding how to implement filtering efficiently was probably the most involved design discussion we had.

The core problem is that within a single index, different vectors can have different metadata keys. LanceDB supports efficient filtering through typed scalar columns with btree, bitmap, or label_list indexes, but those columns have to exist at table creation time. Flattening every possible metadata key into a dedicated column produces an unbounded schema — impractical, and the AWS API provides no mechanism to define one at index creation time.

We plan to apply our own JSON based filtering that aligns with the vectors API. This will require us to over-fetch by inflating the top-K request size, to retrieve a larger candidate pool from the ANN index before applying the filter, returning the top-K survivors. For highly selective filters, we could also tune nprobes to reduce the likelihood of returning fewer than K results when only a small fraction of vectors match the predicate.

The reason we default to post-filtering rather than pre-filtering is SDK compatibility. Post-filtering requires no schema knowledge upfront, works against the metadata JSON column that any client including the AWS SDK will produce, and delivers the same semantics AWS describes — filtering in tandem with candidate retrieval, with the caveat that fewer than K results may be returned for highly selective predicates.

For callers who need stronger correctness or performance guarantees, the optional filterableMetadataKeys extension on CreateIndex defines typed scalar columns upfront. When those columns are present we can use LanceDB's pre-filtering instead, narrowing the candidate set before the vector search runs rather than after. Pre-filtering is generally more efficient for selective filters and eliminates the "fewer than K results" edge case entirely. This will be a Ceph extension — the AWS SDKs has no field for it — but it is opt-in, not required.

The result is a tiered approach: compatible behavior by default for any client including the AWS SDKs, with a more precise and efficient path available through the extension for callers who know their filter schema upfront.

AWS SDK Compatibility ¶

The post-filtering approach resolves any compatibility concerns.

PutVectors, GetVectors, DeleteVectors, ListVectors, CreateIndex, and unfiltered QueryVectors all map directly to the AWS API surface without divergence.

QueryVectors with a filter predicate will work correctly via post-filtering even without scalarSchema — the results are accurate, derived from scanning a broader candidate set rather than using a scalar index. The performance difference is workload-dependent: for highly selective filters (where few vectors match) the overhead is minimal; for low-selectivity filters the oversampling multiplier can be tuned.

The one remaining translation layer is filter expression syntax. AWS defines filter expressions as a JSON structure against its filterable/non-filterable metadata model; LanceDB operates on SQL WHERE clauses. We will parse the S3 Vectors JSON filter syntax and convert it to the appropriate LanceDB predicate internally — this is an implementation detail, not a compatibility constraint. From the perspective of any client using the AWS SDK, filtered QueryVectors calls work correctly without modification.

Current Status ¶

Two open pull requests against ceph/ceph:

ceph/ceph#66066 is the main integration PR tracking 34 tasks. Vector bucket CRUD, IAM auth/policy, index management, PutVectors, GetVectors, DeleteVectors, ListVectors, and QueryVectors are implemented. Vector Bucket Policy APIs and per-index VectorBucket attributes — for caching schema and distance metric between calls rather than reconstructing them from the table on every request — are in progress.

Beyond these we need to work on finalizing the plumbing to the radosgw storage abstraction layer, implement post-filtering for QueryVectors, and add policy actions and server-side encryption support.

Scope ¶

S3 Vectors in Ceph is not a replacement for a dedicated vector database. If the workload requires single-digit millisecond latency, rich full-text plus vector hybrid search, or a complex query DSL, a dedicated system is still the right answer. S3 Vectors targets workloads where the requirement is cost-effective storage of large numbers of vectors with sub-second ANN search and simple metadata filtering — in a cluster that already runs Ceph, and doubly so if the data the embeddings have been extracted from already exists in Ceph object storage.

Get Involved ¶

The pull requests above are the best place to engage. We are also in #rgw-devel on the Ceph Slack. Patches welcome.
